The Pentair IntelliChlor salt chlorine generator offers a convenient alternative to traditional chlorine. It utilizes common salt to produce chlorine, eliminating the need to purchase, store, and handle harsh chemicals. This system provides consistent sanitation for your pool.
What is the Pentair IntelliChlor?
The Pentair IntelliChlor is an automatic chlorine generator designed for swimming pools. It is an innovative system that uses common table salt to produce chlorine through electrolysis. This process eliminates the need for traditional chlorine tablets or liquid chlorine. Instead of manually adding chlorine, the IntelliChlor maintains consistent sanitation levels in your pool water. This system effectively converts salt into chlorine and then back into salt after the chlorination process, creating a continuous cycle. The IntelliChlor reduces the need for purchasing, storing, and handling harsh chemicals. It provides a safer and more convenient method of pool sanitization, offering softer, silkier pool water. The IntelliChlor aims to simplify pool maintenance with its automated chlorination process.
How the IntelliChlor Works
The IntelliChlor uses electrolysis to convert dissolved salt into chlorine. This chlorine sanitizes the pool water, and then reverts back into salt. This process creates a continuous and efficient sanitation cycle.
Producing Chlorine from Salt
The Pentair IntelliChlor system employs a process known as electrolysis to generate chlorine. This process begins with the addition of common table salt to your pool water. Once dissolved, this salt, composed of sodium chloride, passes through the IntelliChlor cell. Inside the cell, an electrical current is applied, which separates the sodium and chloride ions. The chloride ions then convert into chlorine gas, a potent disinfectant; This generated chlorine effectively sanitizes the pool water, killing bacteria and algae. This process eliminates the need for traditional chlorine addition, streamlining pool maintenance and reducing the handling of harsh chemicals. The IntelliChlor ensures a continuous and automatic supply of chlorine.
The Chlorine Cycle
The IntelliChlor system operates within a closed-loop cycle. Initially, salt is dissolved in the pool water. The system then converts this salt into chlorine through electrolysis. This freshly produced chlorine actively sanitizes the pool, eliminating bacteria and algae. Once the chlorine has completed its sanitizing duty, it reverts back into its original form, dissolved salt. This means that the salt is not consumed but rather recycled. This process is continuous, ensuring a steady level of sanitation. The salt level does diminish over time due to water loss, backwashing, and splash-out, and needs to be replenished periodically to ensure the system can continue to function correctly. This method is efficient and environmentally sound.
IntelliChlor Models and Compatibility
Pentair offers various IntelliChlor models, such as the IC40 and IC20, catering to different pool sizes. Compatibility with the IntelliChlor Power Center ensures seamless integration. Aftermarket options are also available for some models.
IntelliChlor IC40
The Pentair IntelliChlor IC40 is a popular salt chlorine generator known for its ability to effectively sanitize residential pools. This model uses common table salt to produce chlorine, providing a consistent and automatic sanitation process. The IC40 is designed to handle larger pools, offering a robust and reliable performance. It eliminates the need to manually add chlorine, reducing the hassle of purchasing, storing, and handling chemical compounds. The IC40 is an Eco Select Choice, as it reduces the need for traditional chlorine products, minimizing resources used in production, packaging, and transportation. It provides a consistent and reliable method of pool sanitation. It is designed to be compatible with the IntelliChlor Power Center and is known for its ease of use and dependable performance.
IntelliChlor IC20 and Aftermarket Options
The Pentair IntelliChlor IC20 is another model in the IntelliChlor series, designed for smaller pools. It operates on the same principle as the IC40, using common salt to generate chlorine. While Pentair manufactures the IC20, there are aftermarket options available such as the APX PERFORMANCE P20 cell. These aftermarket cells are designed to be compatible with the IC20 system, providing an alternative for replacement. It’s important to note that these aftermarket options are not manufactured, endorsed, or sold by Pentair. These options can offer a cost-effective solution for those needing to replace their salt cell. Always ensure compatibility and reliability when considering aftermarket alternatives. The IC20 provides the same sanitation performance as the IC40, but for smaller pools. The APX PERFORMANCE P20 is a direct replacement that fits the IC20.
IntelliChlor Plus & LT Series
In late 2024, Pentair announced the IntelliChlor Plus and LT series of salt chlorine generators, which were slated for release in Spring 2025. These redesigned cells maintain the same form factor as their predecessors, ensuring compatibility with existing IntelliChlor Power Centers. The IntelliChlor Plus and LT series represent an evolution in Pentair’s salt chlorination technology. While specific details of their improvements are not fully disclosed, they are designed to provide the same reliable and efficient chlorine generation. This series offers advanced features while retaining compatibility with existing systems, making upgrades seamless for current IntelliChlor users. The new models are an alternative that could be considered.
Operation and Maintenance
Operating the IntelliChlor involves a start-up procedure, adjusting chlorine output, and monitoring salt levels. Regular maintenance, including cell cleaning, is essential for optimal performance and longevity of the system.
Start-Up Procedure
The initial start-up of your Pentair IntelliChlor system is a crucial process that requires careful attention to detail; Begin by ensuring that all electrical connections are properly made, following the provided wiring instructions to prevent electrical hazards. Verify the salt level in your pool using an independent testing device such as strips or an electronic tester to make sure the salinity is adequate for the system to function correctly. Low salt levels will prevent chlorine production, while excessive salt can damage the cell. After adding the necessary salt, allow it to fully dissolve and circulate through the pool water. Once this is done, power on your IntelliChlor unit and allow it to start generating chlorine. Monitor the system’s performance closely to ensure proper operation. If the salt level is too low the cell will shut down.
Adjusting Chlorine Output
The Pentair IntelliChlor system allows you to easily adjust the chlorine output to meet your pool’s specific needs. The system automatically produces chlorine, but you can fine-tune the output level to maintain optimal sanitization. The adjustment is typically made through the control panel on your unit or via a connected automation system. Begin by gradually increasing or decreasing the output percentage, as needed. It is best to make small adjustments and monitor the effect on your pool’s chlorine level before making further changes. Regularly test your pool water to ensure the chlorine level is within the recommended range for safe and effective sanitation, and adjust the output to achieve the desired level. The system will do the rest of the work.
Salt Level Monitoring and Adjustment
Maintaining the correct salt level is crucial for your Pentair IntelliChlor system to function properly. The system will not work if there is an incorrect amount of salt. Regularly monitor the salt level using a reliable testing method. This can be done with salt test strips or an electronic salt tester. If the salt level is too low, the system may shut down or not produce enough chlorine. Conversely, excessively high salt levels can also be problematic. If adjustment is needed, slowly add salt to the pool, ensuring it is thoroughly dissolved before retesting. Always follow the manufacturer’s guidelines for the recommended salt concentration for your particular IntelliChlor model.
Troubleshooting
If your IntelliChlor system malfunctions, check the power supply and salt level first. Issues can arise from low salt or a tripped breaker. Cell cleaning may also be required.
Checking Power Supply
When troubleshooting your Pentair IntelliChlor system, verifying the power supply is a crucial first step. Ensure the IntelliChlor is receiving the proper voltage, as inadequate power can prevent it from functioning correctly. Check the circuit breaker associated with the unit to make sure it hasn’t tripped. A tripped breaker will cut off power, halting the chlorine generation process. It’s important to confirm that all wiring connections are secure and free from damage. Use a multimeter if needed to measure the voltage at the unit’s connection points. If power is not reaching the IntelliChlor, consult a qualified electrician to diagnose and rectify any underlying electrical issues. Remember, safety is paramount when dealing with electrical components; always disconnect the power before inspecting wiring or connections.
Addressing Low Salt Levels
Low salt levels are a common issue that can prevent your Pentair IntelliChlor system from generating chlorine effectively. If the salt level is too low, the IntelliChlor will typically shut down to prevent damage. The system may indicate a low salt condition with a red light on the salt display. Before adding more salt, manually test the water using salt test strips or an electronic tester to obtain an accurate reading. Adding salt without testing could lead to over-salination. If the test confirms a low salt level, carefully add the appropriate amount of common table salt according to the manufacturer’s instructions. Allow the system to circulate for 24 hours to ensure the salt dissolves completely, then recheck the salt level and make any necessary adjustments. Be sure that the salt is fully dissolved, not just settled at the bottom of the pool.
Cell Cleaning and Acid Washing
Over time, calcium scale and other mineral deposits can accumulate on the Pentair IntelliChlor salt cell, reducing its efficiency. Regular cell cleaning is crucial for maintaining optimal chlorine production. Before cleaning, disconnect power to the unit. Inspect the cell for any visible scale or debris. If scaling is present, an acid wash is recommended. Use a specialized acid cleaning kit designed for IntelliChlor cells, following the manufacturer’s instructions carefully. This typically involves soaking the cell in a diluted acid solution to dissolve the mineral buildup. After acid washing, thoroughly rinse the cell with clean water and visually inspect it to ensure all scale is removed. Regular cell cleaning and acid washing will maintain the cell’s performance and longevity. Always follow safety instructions when handling acid.
Safety and Installation
Proper installation of the IntelliChlor salt chlorine generator requires careful attention to electrical wiring and safety. Always follow the manufacturer’s instructions and safety guidelines to prevent electrical shock and ensure safe operation.
Electrical Wiring Instructions
When installing the Pentair IntelliChlor salt chlorine generator, it is crucial to adhere to all electrical wiring instructions provided in the manual. Before commencing any wiring work, ensure that the power supply to the system is completely disconnected. The IntelliChlor requires a dedicated power circuit. Verify the correct voltage and amperage requirements for your specific model. Connect the power wires according to the wiring diagram in the manual, paying close attention to polarity. Use appropriate wiring connectors and ensure that all connections are secure and protected from moisture. It is recommended to consult a qualified electrician if you are not comfortable with electrical wiring. Incorrect wiring can lead to damage to the generator or pose a significant safety hazard. Always double-check all connections before restoring power to the unit. Follow all local electrical codes.
Safety Precautions
Prior to installing or operating the Pentair IntelliChlor salt chlorine generator, it’s imperative to thoroughly read and understand all safety precautions outlined in the manual. To mitigate the risk of electrical shock, always ensure the power is off before handling any electrical components. The IntelliChlor should be installed a minimum of five feet away from the pool. Follow all chemical manufacturer’s instructions when handling pool chemicals. Never attempt to bypass any safety features of the unit. If you are uncertain about any aspect of the installation or operation, seek professional assistance. Regularly inspect the system for any signs of damage or wear. Children and pets should always be supervised around pool equipment. Proper grounding is essential for safe operation. Ignoring safety precautions may result in personal injury or damage to the equipment.
